1 inch red molded heater hose
Basic Info
Model No.: ARH
Product Description
Features:
1 inch red molded heater hose
·Good Quality EPDM Materials
·Heat, ozone and weather resistance
·ISO/TS 16949:2009 Registered
Description:
Inner Tube: Black EPDM suitable for ethylene glycol solutions
Outer Tube: Black smooth EPDM, with good heat, ozone and weather resistance
Reinforced layer: High tensile synthetic yarn (Polyester)
Temperature: -30C ~ +110C(peaking to 120c)
Safety Factor: 3:1
For conveyance of hot water predominantly in vehicles
Specifications
| No | ID | OD | W.P | B.P | |||
| Inch | mm | mm | Bar | PSI | Bar | PSI | |
| 1 | 3/16'' | 5 | 11.5 | 20 | 300 | 60 | 900 |
| 2 | 1/4'' | 6 | 13 | 20 | 300 | 60 | 900 |
| 3 | 5/16'' | 8 | 15 | 20 | 300 | 60 | 900 |
| 4 | 3/8'' | 10 | 17 | 20 | 300 | 60 | 900 |
| 5 | 1/2'' | 13 | 22 | 20 | 300 | 60 | 900 |
| 6 | 5/8'' | 16 | 25 | 20 | 300 | 60 | 900 |
| 7 | 3/4'' | 19 | 29 | 20 | 300 | 60 | 900 |
| 8 | 1'' | 25 | 36 | 20 | 300 | 60 | 900 |
| 9 | 1-1/4'' | 32 | 43 | 10 | 150 | 30 | 450 |
| 10 | 1-1/2'' | 38 | 50 | 10 | 150 | 30 | 450 |
| 11 | 2' | 51 | 65 | 10 | 150 | 30 | 450 |
